将 Chartboost 与中介集成

This guide shows you how to use the Google Mobile Ads SDK to load and display ads from Chartboost using mediation, covering waterfall integrations. It covers how to add Chartboost to an ad unit's mediation configuration, and how to integrate the Chartboost SDK and adapter into a Unity app.

Supported integrations and ad formats

The AdMob mediation adapter for Chartboost has the following capabilities:

Integration
Bidding
Waterfall
Formats
Banner
Interstitial
Rewarded

Requirements

  • Unity 4 or higher
  • Latest Google Mobile Ads SDK
  • To deploy on Android
    • Android API level 21 or higher
  • To deploy on iOS
    • iOS deployment target of 12.0 or higher
  • A working Unity project configured with Google Mobile Ads SDK. See Get Started for details.
  • Complete the mediation Get started guide

Step 1: Set up configurations in Chartboost UI

注册 Chartboost 账号，并在账号通过验证后登录。 然后，转到应用管理标签页。

Chartboost 应用信息中心

点击 Add new app 按钮创建应用。

应用管理

填写表单的其余部分，然后点击 Add App（添加应用）按钮，完成应用。

新建应用表单

创建应用后，系统会将您定向到该应用的信息中心。记下应用的应用 ID 和应用签名。

Android

应用设置

iOS

应用设置

AdMob 需要 Chartboost 用户 ID 和用户签名，用于设置您的 AdMob 广告单元 ID。您可以通过点击 Chartboost 界面中的 Chartboost 中介找到这些参数。

Chartboost 中介信息中心

转到资源 > API Explorer 标签页，并记下身份验证部分下的用户 ID 和用户签名。

Chartboost API Explorer

开启测试模式

您可以为应用启用测试模式，方法是从 Chartboost 界面中转到应用管理标签页，从列表中选择您的应用，然后点击 Edit app settings（修改应用设置）。

Android

修改应用设置

iOS

修改应用设置

在应用的设置中，您可以开启/关闭应用的测试模式。

Chartboost 测试模式

启用测试模式后，您可以使用之前创建的广告单元 ID 请求广告，并接收 Chartboost 测试广告。

在您能够收到 Chartboost 测试广告后，您的应用将会参与 Chartboost 的 Publisher App Review 审核。为了确保 Chartboost 能够正常使用创收功能，发布商应用审核需要获得 Chartboost 的批准。

Step 2: Set up Chartboost demand in AdMob UI

为广告单元配置中介设置

Android

如需了解相关说明，请参阅 Android 指南中的第 2 步。

iOS

如需了解相关说明，请参阅 iOS 指南中的第 2 步。

Add Chartboost to GDPR and US state regulations ad partners list

按照 GDPR 设置 和 美国州级法规设置 中的步骤，将 Chartboost 添加到 AdMob 界面中的 GDPR 和美国州级法规广告合作伙伴列表中。

Step 3: Import the Chartboost SDK and adapter

Download the latest version of Google Mobile Ads mediation plugin for Chartboost from the download link in the Changelog and extract GoogleMobileAdsChartboostMediation.unitypackage from the zip file.

In your Unity project editor, select Assets > Import Package > Custom Package and find the GoogleMobileAdsChartboostMediation.unitypackage file you downloaded. Make sure that all the files are selected and click Import.

Then, select Assets > Play Services Resolver > Android Resolver > Force Resolve. The Unity Play Services Resolver library will perform dependency resolution from scratch and copy the declared dependencies into the Assets/Plugins/Android directory of your Unity app.

Step 4: Implement privacy settings on Chartboost SDK

Under the Google EU User Consent Policy, you must ensure that certain disclosures are given to, and consents obtained from, users in the European Economic Area (EEA) regarding the use of device identifiers and personal data. This policy reflects the requirements of the EU ePrivacy Directive and the General Data Protection Regulation (GDPR). When seeking consent, you must identify each ad network in your mediation chain that may collect, receive, or use personal data and provide information about each network's use. Google currently is unable to pass the user's consent choice to such networks automatically.

The Google Mobile Ads mediation plugin for Chartboost version 3.1.0 includes the Chartboost.AddDataUseConsent() method. The following sample code sets data use consent to NonBehavioral. If you choose to call this method, it is recommended that you do so prior to requesting ads using the Google Mobile Ads SDK.

using GoogleMobileAds.Api.Mediation.Chartboost;
// ...

Chartboost.AddDataUseConsent(CBGDPRDataUseConsent.NonBehavioral);

US states privacy laws

U.S. states privacy laws require giving users the right to opt out of the "sale" of their "personal information" (as the law defines those terms), with the opt-out offered via a prominent "Do Not Sell My Personal Information" link on the "selling" party's homepage. The U.S. states privacy laws compliance guide offers the ability to enable restricted data processing for Google ad serving, but Google is unable to apply this setting to each ad network in your mediation chain. Therefore, you must identify each ad network in your mediation chain that may participate in the sale of personal information and follow guidance from each of those networks to ensure compliance.

The Google Mobile Ads mediation plugin for Chartboost version 3.1.0 includes the Chartboost.AddDataUseConsent() method. The following sample code sets data use consent to OptInSale. If you choose to call this method, it is recommended that you do so prior to requesting ads using the Google Mobile Ads SDK.

using GoogleMobileAds.Api.Mediation.Chartboost;
// ...

Chartboost.AddDataUseConsent(CBCCPADataUseConsent.OptInSale);

Step 5: Add required code

Android

No additional code is required for Chartboost integration.

iOS

SKAdNetwork integration

Follow Chartboost's documentation to add the SKAdNetwork identifiers to your project's Info.plist file.

Step 6: Test your implementation

启用测试广告

请务必为AdMob 注册您的测试设备，并在 Chartboost 界面中启用测试模式。

验证测试广告

如需验证您收到的是来自Chartboost的测试广告，请使用相应广告来源在广告检查器中启用单一广告来源测试。 Chartboost (Waterfall)

Optional Steps

Android

Permissions

For optimal performance, Chartboost recommends adding the following optional permissions to your app's AndroidManifest.xml file:

<uses-permission android:name="android.permission.READ_PHONE_STATE" />

iOS

No additional steps are required for iOS integration.

Error codes

If the adapter fails to receive an ad from Chartboost, publishers can check the underlying error from the ad response using ResponseInfo under the following classes:

Android

com.google.ads.mediation.chartboost.ChartboostAdapter
com.google.ads.mediation.chartboost.ChartboostMediationAdapter

iOS

GADMAdapterChartboost
GADMediationAdapterChartboost

Here are the codes and accompanying messages thrown by the Chartboost adapter when an ad fails to load:

Android

Error code Reason
0-99 Chartboost SDK returned an error.
101 The requested ad size does not match a Chartboost supported banner size.
102 Chartboost can only load 1 ad per location at a time.
103 Chartboost server parameters configured in the AdMob UI are missing/invalid.
104 The Chartboost interstitial or rewarded ad is not ready to be shown.

iOS

Error code Reason
101 Chartboost server parameters configured in the AdMob UI are missing/invalid.
102 The Chartboost SDK returned an initialization error.
103 The Chartboost ad is not cached at show time.
104 The requested ad size does not match a Chartboost supported banner size.
105 Device's OS version is lower than Chartboost SDK's minimum supported OS version.
200-299 Chartboost SDK cache errors. See code for more details.
300-399 Chartboost SDK show errors. See code for more details.
400-499 Chartboost SDK click errors. See code for more details.

Chartboost Unity Mediation Plugin Changelog

Version 4.6.0

Version 4.5.0

Version 4.4.0

Version 4.3.0

Version 4.2.0

Version 4.1.1

Version 4.1.0

Version 4.0.0

Version 3.5.1

Version 3.5.0

Version 3.4.1

Version 3.4.0

Version 3.3.1

Version 3.3.0

Version 3.2.0

Version 3.1.0

Version 3.0.1

Version 3.0.0

Version 2.0.1

Version 2.0.0

  • Supports Chartboost Android adapter version 7.5.0.0.
  • Supports Chartboost iOS adapter version 8.0.1.1.

Version 1.3.0

  • Updated the plugin to support the new Rewarded API.
  • Supports Chartboost Android adapter version 7.3.1.1.
  • Supports Chartboost iOS adapter version 7.5.0.0.

Version 1.2.0

  • Supports Chartboost Android adapter version 7.3.0.0.
  • Supports Chartboost iOS adapter version 7.3.0.0.

Version 1.1.1

  • Supports Chartboost Android adapter version 7.2.0.1.
  • Supports Chartboost iOS adapter version 7.2.0.1.

Version 1.1.0

  • Supports Chartboost Android SDK version 7.2.0.
  • Supports Chartboost iOS SDK version 7.2.0.
  • Added Chartboost.RestrictDataCollection() method to enable GDPR data collection restrictions for the Chartboost SDK.

Version 1.0.0

  • First release!
  • Supports Chartboost Android SDK version 7.0.1.
  • Supports Chartboost iOS SDK version 7.1.2.
