Revoke by issuer

In this phase, the Issuer revokes the VDC after it has been issued to a user. This will remove the local VDCs from all devices. The user will no longer have the option to add the VDC to another device (including the same one) in the future.

Note: This scenario is different from a user deleting the VDC from their device. When a user deletes the VDC from their Google Wallet app, it is removed from that device only. The VDC remains active with the Issuer and can be added to another dvice (including the same one) in the future.

Request flow

Flow description

Step	Source	Description
1	Issuer servers	The Issuer revokes the VDC and notifies Google by calling the `notifyCredentialStatusUpdateAvailable` method.
2	Google	Google uses the `getCredentialStatus` method to request the new status of the VDC.
3	Issuer servers	The Issuer returns the `revoked` status.
4	Google	Google notifies the user's device(s) that the credential has been revoked.
5	Android-powered device	The user's devices delete the VDC from the Google Wallet app and notify Google on success.
6	Google	Google notifies the Issuer that the VDC has been deleted from the user's device(s).
