The provisioning phase occurs once an issuer has approved a proofing request. In this phase, an VDC credential and mobile security objects (MSO) are saved to the user's device. These can then be used when proceeding the VDC to relying parties.
Request flow
Flow description
| Step | Source | Description |
|---|---|---|
| 1 | Android-powered device |
The Google Wallet app calls provisionCredential once it has
been notified that the proofing request has been accepted.
|
| 2 | Google servers |
Google calls provisionCredential, supplying the credential
ID and the proofing ID.
|
| 3 | Issuer servers | The Issuer returns the VDC and an Issuer-generated credential version ID. |
| 4 | Google servers | Google relays the response to the user. |
| 5 | Android-powered device |
The Google Wallet app calls provisionMobileSecurityObjects,
supplying the credential ID, a list of x509 certificates to be
certified, and proof that provisioning has completed successfully.
|
| 6 | Issuer servers | The Issuer returns the MSOs. |
| 7 | Google servers | Google relays the MSOs to the user. |
