ChromeOS Compatible - 3.5mm Headset Specification v1.3
Stay organized with collections
Save and categorize content based on your preferences.
Version: 1.3.1
Last updated: 2024-06-17
Legend
| Product Verb |
Development Action |
| "MUST" |
Mandatory product requirement |
| "SHOULD" |
Optional recommendation |
| "MAY" |
Nice to have |
Overview
This document describes the requirements a ChromeOS Compatible wired headset
meets. This specification is not for WWCB products, nor for a product designed
and certified together with a Chromebook.
3.5mm audio connector hardware specifications
Plug
- Mechanical
- 4 conductor 3.5mm plug
- Pinout order
- CTIA (LRGM) - Recommended
- OMTP(LRMG) - Optional
- Electrical
- Ear speaker impedance
- Mic equivalent DC resistance
(Source:
https://source.android.com/devices/accessories/headset/plug-headset-spec )
Audio Quality
Capture Path - Mute
- If there is any interface for users to mute the audio device, it must
- Maintain the mute state in a way that is not affected by:
- Opening and closing the device.
- Switching to another input device.
- If the user presses the mute button on the headset or ChromeOS, the
mute state must change.
- If the mute state changes, the mute state indicator (eg:LED) on the
headset must change.
Audio Latency
Latency
- Output Latency
- Audio playback must begin ≤500 ms after a user action that
initiates playback.
- May request a waiver if the device OEM can prove that no echo is
introduced when it fails this requirement.
A/V Sync
- Audio playback should be synchronized with video playback. Audio playback
may lead the video by ≤25 ms or trail the video by ≤95 ms.
Revision History
| Date |
Version |
Notes |
| 2024-06-17 |
1.3.1 |
ChromeOS Compatible spec derived. Initial Partner Site Publication. |
| 2022-09-01 |
1.3 |
Related WWCB specification v1.3 |
| 2022-06-06 |
1.2 |
Related WWCB specification v1.2 |
| 2020-10-14 |
1.1 |
Related WWCB specification v1.1 |
| 2020-09-23 |
1.0 |
Related WWCB specification created. |
