# Machine Learning Glossary

This glossary defines general machine learning terms as well as terms specific to TensorFlow.

## A

## A/B testing

A statistical way of comparing two (or more) techniques, typically an incumbent against a new rival. A/B testing aims to determine not only which technique performs better but also to understand whether the difference is statistically significant. A/B testing usually considers only two techniques using one measurement, but it can be applied to any finite number of techniques and measures.

## accuracy

The fraction of predictions that a
**classification model** got right. In
**multi-class classification**, accuracy
is defined as follows:

In **binary classification**, accuracy has
the following definition:

See **true positive** and
**true negative**.

## activation function

A function (for example, **ReLU** or **sigmoid**)
that takes in the weighted sum of all of the inputs from the previous layer
and then generates and passes an output value (typically nonlinear) to the next
layer.

## AdaGrad

A sophisticated gradient descent algorithm that rescales the
gradients of each parameter, effectively giving each parameter
an independent **learning rate**. For a full explanation, see
this paper.

## AUC (Area under the ROC Curve)

An evaluation metric that considers all possible
**classification thresholds**.

The Area Under the ROC curve is the probability that a classifier will be more confident that a randomly chosen positive example is actually positive than that a randomly chosen negative example is positive.

## B

## backpropagation

The primary algorithm for performing
**gradient descent** on
**neural networks**. First, the output values
of each node are calculated (and cached) in a forward pass.
Then, the
partial derivative
of the error with respect to each parameter is calculated in a backward
pass through the graph.

## baseline

A simple **model** or heuristic used as reference point for comparing
how well a model is performing. A baseline helps model developers quantify
the minimal, expected performance on a particular problem.

## batch

The set of examples used in one **iteration** (that is, one
**gradient** update) of
**model training**.

See also **batch size**.

## batch size

The number of examples in a **batch**. For example, the batch size
of **SGD** is 1, while the batch size of
a **mini-batch** is usually between 10 and 1000. Batch size is
usually fixed during training and inference; however, TensorFlow does permit
dynamic batch sizes.

## bias

An intercept or offset from an origin. Bias (also known as the
**bias term**) is referred to as *b* or *w _{0}* in
machine learning models. For example, bias is the

*b*in the following formula:

Not to be confused with **prediction bias**.

## binary classification

A type of classification task that outputs one of two mutually exclusive classes. For example, a machine learning model that evaluates email messages and outputs either "spam" or "not spam" is a binary classifier.

## binning

See **bucketing**.

## bucketing

Converting a (usually **continuous**) feature into
multiple binary features called buckets or bins, typically based on value
range. For example, instead of representing temperature as a single
continuous floating-point feature, you could chop ranges of temperatures
into discrete bins. Given temperature data sensitive to a tenth of a degree,
all temperatures between 0.0 and 15.0 degrees could be put into one bin,
15.1 to 30.0 degrees could be a second bin, and 30.1 to 50.0 degrees could
be a third bin.

## C

## calibration layer

A post-prediction adjustment, typically to account for
**prediction bias**. The adjusted predictions and
probabilities should match the distribution of an observed set of labels.

## candidate sampling

A training-time optimization in which a probability is calculated for all
the positive labels, using, for example, softmax, but only for a random
sample of negative labels. For example, if we have an example labeled
*beagle* and *dog* candidate sampling computes the predicted probabilities
and corresponding loss terms for the *beagle* and *dog* class outputs
in addition to a random subset of the remaining classes
(*cat*, *lollipop*, *fence*). The idea is that the
**negative classes** can learn from less frequent
negative reinforcement as long as
**positive classes** always get proper positive
reinforcement, and this is indeed observed empirically. The motivation for
candidate sampling is a computational efficiency win from not computing
predictions for all negatives.

## categorical data

**Features** having a discrete set of possible values. For example,
consider a categorical feature named `house style`

, which has a discrete set of
three possible values: `Tudor, ranch, colonial`

. By representing `house style`

as categorical data, the model can learn the separate impacts of `Tudor`

,
`ranch`

, and `colonial`

on house price.

Sometimes, values in the discrete set are mutually exclusive, and only one
value can be applied to a given example. For example, a `car maker`

categorical feature would probably permit only a single value (`Toyota`

)
per example. Other times, more than one value may be applicable. A single
car could be painted more than one different color, so a `car color`

categorical feature would likely permit a single example to have multiple
values (for example, `red`

and `white`

).

Categorical features are sometimes called
**discrete features**.

Contrast with **numerical data**.

## checkpoint

Data that captures the state of the variables of a model at a particular
time. Checkpoints enable exporting model **weights**, as well
as performing training across multiple sessions. Checkpoints also enable
training to continue past errors (for example, job preemption). Note that
the **graph** itself is not included in a checkpoint.

## class

One of a set of enumerated target values for a label. For example, in a
**binary classification** model that detects
spam, the two classes are *spam* and *not spam*. In a
**multi-class classification** model that
identifies dog breeds, the classes would be *poodle*, *beagle*, *pug*, and so
on.

## class-imbalanced data set

A **binary classification** problem in which the
**labels** for the two classes have significantly different
frequencies. For example, a disease data set in which 0.0001 of examples
have positive labels and 0.9999 have negative labels is a class-imbalanced
problem, but a football game predictor in which 0.51 of examples label one
team winning and 0.49 label the other team winning is *not* a
class-imbalanced problem.

## classification model

A type of machine learning model for distinguishing among two or more
discrete classes. For example, a natural language processing classification
model could determine whether an input sentence was in French, Spanish,
or Italian. Compare with **regression model**.

## classification threshold

A scalar-value criterion that is applied to a model's predicted score in order
to separate the **positive class** from the **negative
class**. Used when mapping
**logistic regression** results to
**binary classification**. For example, consider
a logistic regression model that determines the probability of a given email
message being spam. If the classification threshold is 0.9, then logistic
regression values above 0.9 are classified as *spam* and those below
0.9 are classified as *not spam*.

## collaborative filtering

Making predictions about the interests of one user based on the interests of many other users. Collaborative filtering is often used in recommendation systems.

## confusion matrix

An NxN table that summarizes how successful a
**classification model's** predictions were; that is,
the correlation between the label and the model's classification. One axis of
a confusion matrix is the label that the model predicted, and the other axis
is the actual label. N represents the number of classes. In a
**binary classification** problem, N=2. For example,
here is a sample confusion matrix for a binary classification problem:

Tumor (predicted) | Non-Tumor (predicted) | |
---|---|---|

Tumor (actual) | 18 | 1 |

Non-Tumor (actual) | 6 | 452 |

The preceding confusion matrix shows that of the 19 samples that actually had tumors, the model correctly classified 18 as having tumors (18 true positives), and incorrectly classified 1 as not having a tumor (1 false negative). Similarly, of 458 samples that actually did not have tumors, 452 were correctly classified (452 true negatives) and 6 were incorrectly classified (6 false positives).

The confusion matrix of a multi-class confusion matrix can help you determine mistake patterns. For example, a confusion matrix could reveal that a model trained to recognize handwritten digits tends to mistakenly predict 9 instead of 4, or 1 instead of 7. The confusion matrix contains sufficient information to calculate a variety of performance metrics, including precision and recall.

## continuous feature

A floating-point feature with an infinite range of possible values.
Contrast with **discrete feature**.

## convergence

Informally, often refers to a state reached during training in which training
**loss** and validation loss change very little or not at all
with each iteration after a certain number of iterations. In other words, a
model reaches convergence when additional training on the current data will
not improve the model. In deep learning, loss values sometimes stay constant
or nearly so for many iterations before finally descending, temporarily
producing a false sense of convergence.

See also **early stopping**.

See also Boyd and Vandenberghe, Convex Optimization.

## convex function

A function in which the region above the graph of the function is a
**convex set**. The prototypical convex function is
shaped something like the letter **U**. For example, the following
are all convex functions:

By contrast, the following function is not convex. Notice how the region above the graph is not a convex set:

A **strictly convex function** has exactly one local minimum point, which
is also the global minimum point. The classic U-shaped functions are
strictly convex functions. However, some convex functions
(for example, straight lines) are not.

A lot of the common **loss functions**, including the
following, are convex functions:

Many variations of **gradient descent** are
guaranteed to find a point close to the minimum of a
strictly convex function. Similarly, many variations of
**stochastic gradient descent** have a high probability
(though, not a guarantee) of finding a point close to the minimum of a
strictly convex function.

The sum of two convex functions (for example,
L_{2} loss + L_{1} regularization) is a convex function.

**Deep models** are never convex functions.
Remarkably, algorithms designed for
**convex optimization** tend to find
reasonably good solutions on deep networks anyway, even though
those solutions are not guaranteed to be a global minimum.

## convex optimization

The process of using mathematical techniques such as
**gradient descent** to find
the minimum of a **convex function**.
A great deal of research in machine learning has focused on formulating various
problems as convex optimization problems and in solving those problems more
efficiently.

For complete details, see Boyd and Vandenberghe, Convex Optimization.

## convex set

A subset of Euclidean space such that a line drawn between any two points in the subset remains completely within the subset. For instance, the following two shapes are convex sets:

By contrast, the following two shapes are not convex sets:

## cost

Synonym for **loss**.

## cross-entropy

A generalization of **Log Loss** to
**multi-class classification problems**. Cross-entropy
quantifies the difference between two probability distributions. See also
**perplexity**.

## custom Estimator

An **Estimator** that you write yourself by following
these directions.

Contrast with **pre-made Estimators**.

## D

## data set

A collection of **examples**.

## Dataset API (tf.data)

A high-level TensorFlow API for reading data and transforming it into a form
that a machine learning algorithm requires. A `tf.data.Dataset`

object
represents a sequence of elements, in which each element contains one or more
**Tensors**. A `tf.data.Iterator`

object provides access to the
elements of a `Dataset`

.

For details about the Dataset API, see Importing Data in the TensorFlow Programmer's Guide.

## decision boundary

The separator between classes learned by a model in a
**binary class** or
**multi-class classification problems**. For example,
in the following image representing a binary classification problem,
the decision boundary is the frontier between the orange class and
the blue class:

## dense layer

Synonym for **fully connected layer**.

## deep model

A type of **neural network** containing multiple
**hidden layers**. Deep models rely on trainable
nonlinearities.

Contrast with **wide model**.

## dense feature

A **feature** in which most values are non-zero, typically
a **Tensor** of floating-point values. Contrast with
**sparse feature**.

## derived feature

Synonym for **synthetic feature**.

## discrete feature

A **feature** with a finite set of possible values. For example,
a feature whose values may only be *animal*, *vegetable*, or *mineral* is a
discrete (or categorical) feature. Contrast with
**continuous feature**.

## dropout regularization

A form of **regularization** useful in training
**neural networks**. Dropout regularization works by
removing a random selection of a fixed number of the units in a network
layer for a single gradient step. The more units dropped out, the stronger
the regularization. This is analogous to training the network to emulate
an exponentially large ensemble of smaller networks. For full details, see
Dropout: A Simple Way to Prevent Neural Networks from Overfitting.

## dynamic model

A **model** that is trained online in a continuously
updating fashion. That is, data is continuously entering the model.

## E

## early stopping

A method for **regularization** that involves ending
model training *before* training loss finishes decreasing. In early
stopping, you end model training when the loss on a
**validation data set** starts to increase, that is, when
**generalization** performance worsens.

## embeddings

A categorical feature represented as a continuous-valued feature. Typically, an embedding is a translation of a high-dimensional vector into a low-dimensional space. For example, you can represent the words in an English sentence in either of the following two ways:

- As a million-element (high-dimensional)
**sparse vector**in which all elements are integers. Each cell in the vector represents a separate English word; the value in a cell represents the number of times that word appears in a sentence. Since a single English sentence is unlikely to contain more than 50 words, nearly every cell in the vector will contain a 0. The few cells that aren't 0 will contain a low integer (usually 1) representing the number of times that word appeared in the sentence. - As a several-hundred-element (low-dimensional)
**dense vector**in which each element holds a floating-point value between 0 and 1. This is an embedding.

In TensorFlow, embeddings are trained by **backpropagating**
**loss** just like any other parameter in a
**neural network**.

## empirical risk minimization (ERM)

Choosing the model function that minimizes loss on the training set. Contrast
with **structural risk minimization**.

## ensemble

A merger of the predictions of multiple **models**. You can create an
ensemble via one or more of the following:

- different initializations
- different
**hyperparameters** - different overall structure

Deep and wide models are a kind of ensemble.

## epoch

A full training pass over the entire data set such that each example has been
seen once. Thus, an epoch represents `N`

/**batch size** training
**iterations**, where `N`

is the total number of examples.

## Estimator

An instance of the `tf.Estimator`

class, which encapsulates logic that builds
a TensorFlow graph and runs a TensorFlow session. You may create your own
**custom Estimators** (as described
here)
or instantiate **pre-made Estimators** created by
others.

## example

One row of a data set. An example contains one or more **features**
and possibly a **label**. See also
**labeled example** and
**unlabeled example**.

## F

## false negative (FN)

An example in which the model mistakenly predicted the
**negative class**. For example, the model
inferred that a particular email message was not spam
(the negative class), but that email message actually was spam.

## false positive (FP)

An example in which the model mistakenly predicted the
**positive class**. For example, the model inferred
that a particular email message was spam (the positive class), but that
email message was actually not spam.

## false positive rate (FP rate)

The x-axis in an **ROC curve**. The FP rate is defined as follows:

## feature

An input variable used in making **predictions**.

## feature columns (FeatureColumns)

A set of related features, such as the set of all possible countries in which users might live. An example may have one or more features present in a feature column.

Feature columns in TensorFlow also encapsulate metadata such as:

- the feature's data type
- whether a feature is fixed length or should be converted to an embedding

A feature column can contain a single feature.

"Feature column" is Google-specific terminology. A feature column is referred to as a "namespace" in the VW system (at Yahoo/Microsoft), or a field.

## feature cross

A **synthetic feature** formed by crossing (multiplying
or taking a Cartesian product of) individual features. Feature crosses help
represent nonlinear relationships.

## feature engineering

The process of determining which **features** might be useful
in training a model, and then converting raw data from log files and other
sources into said features. In TensorFlow, feature engineering often means
converting raw log file entries to **tf.Example**
protocol buffers. See also
tf.Transform.

Feature engineering is sometimes called **feature extraction**.

## feature set

The group of **features** your machine learning model trains on.
For example, postal code, property size, and property condition might
comprise a simple feature set for a model that predicts housing prices.

## feature spec

Describes the information required to extract **features** data
from the **tf.Example** protocol buffer. Because the
tf.Example protocol buffer is just a container for data, you must specify
the following:

- the data to extract (that is, the keys for the features)
- the data type (for example, float or int)
- The length (fixed or variable)

The **Estimator API** provides facilities for producing a
feature spec from a list of
**FeatureColumns**.

## full softmax

See **softmax**. Contrast with
**candidate sampling**.

## fully connected layer

A **hidden layer** in which each **node** is
connected to *every* node in the subsequent hidden layer.

A fully connected layer is also known as a **dense layer**.

## G

## generalization

Refers to your model's ability to make correct predictions on new, previously unseen data as opposed to the data used to train the model.

## generalized linear model

A generalization of **least squares regression**
models, which are based on
Gaussian noise, to other
types of models based on other types of noise,
such as Poisson noise or
categorical noise. Examples of generalized linear models include:

**logistic regression**- multi-class regression
- least squares regression

The parameters of a generalized linear model can be found through convex optimization.

Generalized linear models exhibit the following properties:

- The average prediction of the optimal least squares regression model is equal to the average label on the training data.
- The average probability predicted by the optimal logistic regression model is equal to the average label on the training data.

The power of a generalized linear model is limited by its features. Unlike a deep model, a generalized linear model cannot "learn new features."

## gradient

The vector of **partial derivatives** with respect to
all of the independent variables. In machine learning, the gradient is the
the vector of partial derivatives of the model function. The gradient points
in the direction of steepest ascent.

## gradient clipping

Capping **gradient** values before applying them. Gradient
clipping helps ensure numerical stability and prevents
exploding gradients.

## gradient descent

A technique to minimize **loss** by computing the gradients of
loss with respect to the model's parameters, conditioned on training data.
Informally, gradient descent iteratively adjusts parameters, gradually
finding the best combination of **weights** and bias to
minimize loss.

## graph

In TensorFlow, a computation specification. Nodes in the graph
represent operations. Edges are directed and represent passing the result
of an operation
(a Tensor) as an
operand to another operation. Use
**TensorBoard** to visualize a graph.

## H

## heuristic

A practical and nonoptimal solution to a problem, which is sufficient for making progress or for learning from.

## hidden layer

A synthetic layer in a **neural network** between the
**input layer** (that is, the features) and the
**output layer** (the prediction). A neural network
contains one or more hidden layers.

## hinge loss

A family of **loss** functions for
**classification** designed to find the
**decision boundary** as distant as possible
from each training example,
thus maximizing the margin between examples and the boundary.
**KSVMs** use hinge loss (or a related function, such as
squared hinge loss). For binary classification, the hinge loss function
is defined as follows:

where *y'* is the raw output of the classifier model:

and *y* is the true label, either -1 or +1.

Consequently, a plot of hinge loss vs. (y * y') looks as follows:

## holdout data

**Examples** intentionally not used ("held out") during training.
The **validation data set** and
**test data set** are examples of holdout data. Holdout data
helps evaluate your model's ability to generalize to data other than the
data it was trained on. The loss on the holdout set provides a better
estimate of the loss on an unseen data set than does the loss on the
training set.

## hyperparameter

The "knobs" that you
tweak during successive runs of training a model. For example,
**learning rate** is a hyperparameter.

Contrast with **parameter**.

## hyperplane

A boundary that separates a space into two subspaces. For example, a line is a
hyperplane in two dimensions and a plane is a hyperplane in three dimensions.
More typically in machine learning, a hyperplane is the boundary separating a
high-dimensional space. **Kernel Support Vector Machines** use
hyperplanes to separate positive classes from negative classes, often in a very
high-dimensional space.

## I

## independently and identically distributed (i.i.d)

Data drawn from a distribution that doesn't change, and where each value drawn doesn't depend on values that have been drawn previously. An i.i.d. is the ideal gas of machine learning—a useful mathematical construct but almost never exactly found in the real world. For example, the distribution of visitors to a web page may be i.i.d. over a brief window of time; that is, the distribution doesn't change during that brief window and one person's visit is generally independent of another's visit. However, if you expand that window of time, seasonal differences in the web page's visitors may appear.

## inference

In machine learning, often refers to the process of making predictions by
applying the trained model to **unlabeled examples**.
In statistics, inference refers to the process of fitting the parameters
of a distribution conditioned on some observed data. (See the
Wikipedia article on statistical inference.)

## input function

In TensorFlow, a function that returns input data to the training, evaluation,
or prediction method of an **Estimator**. For example,
the training input function returns a **batch** of features
and labels from the **training set**.

## input layer

The first layer (the one that receives the input data) in
a **neural network**.

## instance

Synonym for **example**.

## interpretability

The degree to which a model's predictions can be readily explained. Deep models
are often non-interpretable; that is, a deep model's different layers can be
hard to decipher. By contrast, linear regression models and **wide
models** are typically far more interpretable.

## inter-rater agreement

A measurement of how often human raters agree when doing a task.
If raters disagree, the task instructions may need to be improved.
Also sometimes called **inter-annotator agreement** or
**inter-rater reliability**. See also
Cohen's kappa,
which is one of the most popular inter-rater agreement measurements.

## iteration

A single update of a model's weights during training. An iteration
consists of computing the gradients of the parameters with respect to the
loss on a single **batch** of data.

## K

## Keras

A popular Python machine learning API. Keras runs on
several deep learning frameworks, including TensorFlow, where it is made
available as
**tf.keras**.

## Kernel Support Vector Machines (KSVMs)

A classification algorithm that seeks to maximize the margin between
**positive** and
**negative classes** by mapping input data vectors
to a higher dimensional space. For example, consider a classification
problem in which the input data
set consists of a hundred features. In order to maximize the margin between
positive and negative classes, KSVMs could internally map those features into
a million-dimension space. KSVMs uses a loss function called
hinge loss.

## L

## L_{1} loss

**Loss** function based on the absolute value of the difference
between the values that a model is predicting and the actual values of
the **labels**. L_{1} loss is less sensitive to outliers
than **L _{2} loss**.

## L_{1} regularization

A type of **regularization** that penalizes weights
in proportion to the sum of the absolute values of the weights. In models
relying on **sparse features**, L_{1}
regularization helps drive the weights of irrelevant or barely relevant
features to exactly 0, which removes those features from the model.
Contrast with **L _{2} regularization**.

## L_{2} loss

See **squared loss**.

## L_{2} regularization

A type of **regularization** that penalizes weights
in proportion to the sum of the *squares* of the weights.
L_{2} regularization helps drive outlier weights (those with
high positive or low negative values) closer to 0 but not quite to 0.
(Contrast with **L1 regularization**.)
L_{2} regularization always improves generalization in linear models.

## label

In supervised learning, the "answer" or "result" portion of an
**example**. Each example in a labeled data set consists of one or
more features and a label. For instance, in a housing data set, the features
might include the number of bedrooms, the number of bathrooms, and the age
of the house, while the label might be the house's price.
in a spam detection dataset, the features might include the subject line, the
sender, and the email message itself, while the label would probably be either
"spam" or "not spam."

## labeled example

An example that contains **features** and a
**label**. In supervised training, models learn from labeled
examples.

## lambda

Synonym for **regularization rate**.

(This is an overloaded term. Here we're focusing on the term's
definition within **regularization**.)

## layer

A set of **neurons** in a
**neural network** that process a set of input
features, or the output of those neurons.

Also, an abstraction in TensorFlow. Layers are Python
functions that take **Tensors** and configuration options
as input and produce other tensors as output. Once the necessary Tensors
have been composed, the user can convert the result into an
**Estimator** via a model function.

## Layers API (tf.layers)

A TensorFlow API for constructing a **deep** neural network
as a composition of layers. The Layers API enables you to build different
types of **layers**, such as:

`tf.layers.Dense`

for a**fully-connected layer**.`tf.layers.Conv2D`

for a convolutional layer.

When writing a **custom Estimator**, you compose Layers
objects to define the characteristics of all the
**hidden layers**.

The Layers API follows the [**Keras**](#Keras] layers API conventions.
That is, aside from a different prefix, all functions in the Layers API
have the same names and signatures as their counterparts in the Keras
layers API.

## learning rate

A scalar used to train a model via gradient descent. During each iteration,
the **gradient descent** algorithm multiplies the
learning rate by the gradient. The resulting product is called the
**gradient step**.

Learning rate is a key **hyperparameter**.

## least squares regression

A linear regression model trained by minimizing
**L _{2} Loss**.

## linear regression

A type of **regression model** that outputs a continuous
value from a linear combination of input features.

## logistic regression

A model that generates a probability for each possible discrete label value in
classification problems by applying a **sigmoid function**
to a linear prediction. Although logistic regression is often used in
**binary classification** problems, it can also be
used in **multi-class** classification problems (where it
becomes called **multi-class logistic regression**
or **multinomial regression**).

## Log Loss

The **loss** function used in binary
**logistic regression**.

## loss

A measure of how far a model's **predictions** are from its
**label**. Or, to phrase it more pessimistically, a measure of
how bad the model is. To determine this value, a model must define a loss
function. For example, linear regression models typically use
**mean squared error** for a loss function,
while logistic regression models use **Log Loss**.

## M

## machine learning

A program or system that builds (trains) a predictive model from input data. The system uses the learned model to make useful predictions from new (never-before-seen) data drawn from the same distribution as the one used to train the model. Machine learning also refers to the field of study concerned with these programs or systems.

## Mean Squared Error (MSE)

The average squared loss per example. MSE is calculated by dividing the
**squared loss** by the number of
**examples**. The values that
**TensorFlow Playground** displays for
"Training loss" and "Test loss" are MSE.

## metric

A number that you care about. May or may not be directly optimized in a
machine-learning system. A metric that your system tries to optimize is
called an **objective**.

## Metrics API (tf.metrics)

A TensorFlow API for evaluating models. For example, `tf.metrics.accuracy`

determines how often a model's predictions match labels. When writing a
**custom Estimator**, you invoke Metrics API functions to
specify how your model should be evaluated.

## mini-batch

A small, randomly selected subset of the entire batch of
**examples** run together in a single iteration of training
or inference. The **batch size** of a mini-batch is usually
between 10 and 1,000. It is much more efficient to calculate the loss on a
mini-batch than on the full training data.

## mini-batch stochastic gradient descent (SGD)

A **gradient descent** algorithm that uses
**mini-batches**. In other words, mini-batch SGD estimates the
gradient based on a small subset of the training data. **Vanilla SGD**
uses a mini-batch of size 1.

## ML

Abbreviation for **machine learning**.

## model

The representation of what an ML system has learned from the training data. This is an overloaded term, which can have either of the following two related meanings:

- The
**TensorFlow**graph that expresses the structure of how a prediction will be computed. - The particular weights and biases of that TensorFlow graph, which are
determined by
**training**.

## model training

The process of determining the best **model**.

## Momentum

A sophisticated gradient descent algorithm in which a learning step depends not only on the derivative in the current step, but also on the derivatives of the step(s) that immediately preceded it. Momentum involves computing an exponentially weighted moving average of the gradients over time, analogous to momentum in physics. Momentum sometimes prevents learning from getting stuck in local minima.

## multi-class classification

Classification problems that distinguish among more than two classes. For
example, there are approximately 128 species of maple trees, so a model
that categorized maple tree species would be multi-class. Conversely, a
model that divided emails into only two categories (*spam* and *not spam*)
would be a **binary classification model**.

## multinomial classification

Synonym for **multi-class classification**.

## N

## NaN trap

When one number in your model becomes a NaN during training, which causes many or all other numbers in your model to eventually become a NaN.

NaN is an abbreviation for "Not a Number."

## negative class

In **binary classification**, one class is
termed positive and the other is termed negative. The positive class is
the thing we're looking for and the negative class is the other possibility.
For example, the negative class in a medical test might be "not tumor."
The negative class in an email classifier might be "not spam."
See also **positive class**.

## neural network

A model that, taking inspiration from the brain, is composed of layers
(at least one of which is **hidden**) consisting of
simple connected units or **neurons** followed by nonlinearities.

## neuron

A node in a **neural network**, typically taking in
multiple input values and generating one output value. The neuron calculates
the output value by applying an
**activation function** (nonlinear transformation)
to a weighted sum of input values.

## node

An overloaded term that means either of the following:

- A neuron in a
**hidden layer**. - An operation in a TensorFlow
**graph**.

## normalization

The process of converting an actual range of values into a standard range of values, typically -1 to +1 or 0 to 1. For example, suppose the natural range of a certain feature is 800 to 6,000. Through subtraction and division, you can normalize those values into the range -1 to +1.

See also **scaling**.

## numerical data

**Features** represented as integers or real-valued numbers.
For example, in a real estate model, you would probably represent the size
of a house (in square feet or square meters) as numerical data. Representing
a feature as numerical data indicates that the feature's values have
a *mathematical* relationship to each other and possibly to the label.
For example, representing the size of a house as numerical data indicates
that a 200 square-meter house is twice as large as a 100 square-meter house.
Furthermore, the number of square meters in a house probably has some
mathematical relationship to the price of the house.

Not all integer data should be represented as numerical data. For example,
postal codes in some parts of the world are integers; however, integer postal
codes should not be represented as numerical data in models. That's because a
postal code of `20000`

is not twice (or half) as potent as a postal code of
10000. Furthermore, although different postal codes *do* correlate to different
real estate values, we can't assume that real estate values at postal code
20000 are twice as valuable as real estate values at postal code 10000.
Postal codes should be represented as **categorical data**
instead.

Numerical features are sometimes called
**continuous features**.

## numpy

An open-source math library that provides
efficient array operations in Python. **pandas** is built
on numpy.

## O

## objective

A metric that your algorithm is trying to optimize.

## offline inference

Generating a group of **predictions**, storing those
predictions, and then retrieving those predictions on demand. Contrast
with **online inference**.

## one-hot encoding

A sparse vector in which:

- One element is set to 1.
- All other elements are set to 0.

One-hot encoding is commonly used to represent strings or identifiers that have a finite set of possible values. For example, suppose a given botany data set chronicles 15,000 different species, each denoted with a unique string identifier. As part of feature engineering, you'll probably encode those string identifiers as one-hot vectors in which the vector has a size of 15,000.

## one-vs.-all

Given a classification problem with N possible solutions, a one-vs.-all
solution consists of N separate
**binary classifiers**—one binary classifier for
each possible outcome. For example, given a model that classifies examples
as animal, vegetable, or mineral, a one-vs.-all solution would provide the
following three separate binary classifiers:

- animal vs. not animal
- vegetable vs. not vegetable
- mineral vs. not mineral

## online inference

Generating **predictions** on demand. Contrast with
**offline inference**.

## Operation (op)

A node in the TensorFlow graph. In TensorFlow, any procedure that creates,
manipulates, or destroys a **Tensor** is an operation. For
example, a matrix multiply is an operation that takes two Tensors as
input and generates one Tensor as output.

## optimizer

A specific implementation of the **gradient descent**
algorithm. TensorFlow's base class for optimizers is
tf.train.Optimizer.
Different optimizers (subclasses of `tf.train.Optimizer`

) account for
concepts such as:

- momentum (Momentum)
- update frequency (AdaGrad = ADAptive GRADient descent; Adam = ADAptive with Momentum; RMSProp)
- sparsity/regularization (Ftrl)
- more complex math (Proximal, and others)

You might even imagine an NN-driven optimizer.

## outliers

Values distant from most other values. In machine learning, any of the following are outliers:

**Weights**with high absolute values.- Predicted values relatively far away from the actual values.
- Input data whose values are more than roughly 3 standard deviations from the mean.

Outliers often cause problems in model training.

## output layer

The "final" layer of a neural network. The layer containing the answer(s).

## overfitting

Creating a model that matches the **training data** so
closely that the model fails to make correct predictions on new data.

## P

## pandas

A column-oriented data analysis API. Many ML frameworks, including TensorFlow, support pandas data structures as input. See pandas documentation.

## parameter

A variable of a model that the ML system trains on its own. For example,
**weights** are parameters whose values the ML system gradually
learns through successive training iterations. Contrast with
**hyperparameter**.

## Parameter Server (PS)

A job that keeps track of a model's **parameters** in a
distributed setting.

## parameter update

The operation of adjusting a model's **parameters** during
training, typically within a single iteration of
**gradient descent**.

## partial derivative

A derivative in which all but one of the variables is considered a constant.
For example, the partial derivative of *f(x, y)* with respect to *x* is the
derivative of *f* considered as a function of *x* alone (that is, keeping *y*
constant). The partial derivative of *f* with respect to *x* focuses only on
how *x* is changing and ignores all other variables in the equation.

## partitioning strategy

The algorithm by which variables are divided across
**parameter servers**.

## performance

Overloaded term with the following meanings:

- The traditional meaning within software engineering. Namely: How fast (or efficiently) does this piece of software run?
- The meaning within ML. Here, performance answers the following question:
How correct is this
**model**? That is, how good are the model's predictions?

## perplexity

One measure of how well a **model** is accomplishing its task.
For example, suppose your task is to read the first few letters of a word
a user is typing on a smartphone keyboard, and to offer a list of possible
completion words. Perplexity, P, for this task is approximately the number
of guesses you need to offer in order for your list to contain the actual
word the user is trying to type.

Perplexity is related to **cross-entropy** as follows:

## pipeline

The infrastructure surrounding a machine learning algorithm. A pipeline includes gathering the data, putting the data into training data files, training one or more models, and exporting the models to production.

## positive class

In **binary classification**, the two possible
classes are labeled as positive and negative. The positive outcome is the
thing we're testing for. (Admittedly, we're simultaneously testing for
both outcomes, but play along.) For example, the positive class in a
medical test might be "tumor." The positive class in an email classifier
might be "spam."

Contrast with **negative class**.

## precision

A metric for **classification models**. Precision
identifies the frequency with which a model was correct when predicting the
**positive class**. That is:

## prediction

A model's output when provided with an input **example**.

## prediction bias

A value indicating how far apart the average of
**predictions** is from the average of **labels**
in the data set.

## pre-made Estimator

An **Estimator** that someone has already built.
TensorFlow provides several pre-made Estimators, including `DNNClassifier`

,
`DNNRegressor`

, and `LinearClassifier`

. You may build your own
pre-made Estimators by following
these instructions.

## pre-trained model

Models or model components (such as **embeddings**) that have
been already been trained. Sometimes, you'll feed pre-trained embeddings
into a **neural network**. Other times, your model will
train the embeddings itself rather than rely on the pre-trained embeddings.

## prior belief

What you believe about the data before you begin training on it. For
example, **L _{2} regularization** relies on
a prior belief that

**weights**should be small and normally distributed around zero.

## Q

## queue

A TensorFlow **Operation** that implements a queue data
structure. Typically
used in I/O.

## R

## rank

Overloaded term in ML that can mean either of the following:

- The number of dimensions in a
**Tensor**. For instance, a scalar has rank 0, a vector has rank 1, and a matrix has rank 2. - The ordinal position of a class in an ML problem that categorizes classes from highest to lowest. For example, a behavior ranking system could rank a dog's rewards from highest (a steak) to lowest (wilted kale).

## rater

A human who provides **labels** in **examples**.
Sometimes called an "annotator."

## recall

A metric for **classification models** that answers
the following question: Out of all the possible positive labels, how many
did the model correctly identify? That is:

$$\text{Recall} = \frac{\text{True Positives}} {\text{True Positives} + \text{False Negatives}} $$

## Rectified Linear Unit (ReLU)

An **activation function** with the following rules:

- If input is negative or zero, output is 0.
- If input is positive, output is equal to input.

## regression model

A type of model that outputs continuous (typically, floating-point) values.
Compare with **classification models**, which
output discrete values, such as "day lily" or "tiger lily."

## regularization

The penalty on a model's complexity. Regularization helps prevent
**overfitting**. Different kinds of regularization include:

**L**_{1}regularization**L**_{2}regularization**dropout regularization****early stopping**(this is not a formal regularization method, but can effectively limit overfitting)

## regularization rate

A scalar value, represented as lambda, specifying the relative importance
of the regularization function. The following simplified **loss**
equation shows the regularization rate's influence:

Raising the regularization rate reduces **overfitting**
but may make the model less **accurate**.

## representation

The process of mapping data to useful **features**.

## ROC (receiver operating characteristic) Curve

A curve of **true positive rate** vs.
**false positive rate** at different
**classification thresholds**. See also
**AUC**.

## root directory

The directory you specify for hosting subdirectories of the TensorFlow checkpoint and events files of multiple models.

## Root Mean Squared Error (RMSE)

The square root of the **Mean Squared Error**.

## S

## SavedModel

The recommended format for saving and recovering TensorFlow models. SavedModel is a language-neutral, recoverable serialization format, which enables higher-level systems and tools to produce, consume, and transform TensorFlow models.

See Saving and Restoring in the TensorFlow Programmer's Guide for complete details.

## Saver

A TensorFlow object responsible for saving model checkpoints.

## scaling

A commonly used practice in **feature engineering**
to tame a feature's range of values to match the range of other features in
the data set. For example, suppose that you want all floating-point features
in the data set to have a range of 0 to 1. Given a particular feature's
range of 0 to 500, you could scale that feature by dividing each value
by 500.

See also **normalization**.

## scikit-learn

A popular open-source ML platform. See www.scikit-learn.org.

## semi-supervised learning

Training a model on data where some of the training examples have labels but others don’t. One technique for semi-supervised learning is to infer labels for the unlabeled examples, and then to train on the inferred labels to create a new model. Semi-supervised learning can be useful if labels are expensive to obtain but unlabeled examples are plentiful.

## sequence model

A model whose inputs have a sequential dependence. For example, predicting the next video watched from a sequence of previously watched videos.

## session

Maintains state (for example, variables) within a TensorFlow program.

## sigmoid function

A function that maps logistic or multinomial regression output (log odds) to probabilities, returning a value between 0 and 1. The sigmoid function has the following formula:

where \(\sigma\) in **logistic regression** problems
is simply:

In other words, the sigmoid function converts \(\sigma\) into a probability between 0 and 1.

In some **neural networks**, the sigmoid function acts as
the **activation function**.

## softmax

A function that provides probabilities for each possible class in a
**multi-class classification model**. The probabilities add up
to exactly 1.0. For example, softmax might determine that the probability of a
particular image being a dog at 0.9, a cat at 0.08, and a horse at 0.02.
(Also called **full softmax**.)

Contrast with **candidate sampling**.

## sparse feature

**Feature** vector whose values are predominately zero or empty.
For example, a vector containing a single 1 value and a million 0 values is
sparse. As another example, words in a search query could also be a
sparse feature—there are many possible words in a given language, but only a
few of them occur in a given query.

Contrast with **dense feature**.

## squared hinge loss

The square of the **hinge loss**. Squared hinge loss penalizes
outliers more harshly than regular hinge loss.

## squared loss

The **loss** function used in
**linear regression**. (Also known as
**L _{2} Loss**.) This function calculates the squares of
the difference between a model's predicted value for a labeled

**example**and the actual value of the

**label**. Due to squaring, this loss function amplifies the influence of bad predictions. That is, squared loss reacts more strongly to outliers than

**L**.

_{1}loss## static model

A model that is trained offline.

## stationarity

A property of data in a data set, in which the data distribution stays constant across one or more dimensions. Most commonly, that dimension is time, meaning that data exhibiting stationarity doesn't change over time. For example, data that exhibits stationarity doesn't change from September to December.

## step

A forward and backward evaluation of one **batch**.

## step size

Synonym for **learning rate**.

## stochastic gradient descent (SGD)

A **gradient descent** algorithm in which the batch size
is one. In other words, SGD relies on a single example chosen uniformly at
random from a data set to calculate an estimate of the gradient at each step.

## structural risk minimization (SRM)

An algorithm that balances two goals:

- The desire to build the most predictive model (for example, lowest loss).
- The desire to keep the model as simple as possible (for example, strong regularization).

For example, a model function that minimizes loss+regularization on the training set is a structural risk minimization algorithm.

For more information, see http://www.svms.org/srm/.

Contrast with **empirical risk minimization**.

## summary

In TensorFlow, a value or set of values calculated at a particular
**step**, usually used for tracking model metrics during training.

## supervised machine learning

Training a **model** from input data and its corresponding
**labels**. Supervised machine learning is analogous to a student
learning a subject by studying a set of questions and their corresponding
answers. After mastering the mapping between questions and answers, the
student can then provide answers to new (never-before-seen) questions on
the same topic. Compare with
**unsupervised machine learning**.

## synthetic feature

A **feature** that is not present among the input features, but is
derived from one or more of them. Kinds of synthetic features include the
following:

- Multiplying one feature by itself or by other feature(s). (These are
termed
**feature crosses**.) - Dividing one feature by a second feature.
**Bucketing**a continuous feature into range bins.

Features created by **normalizing** or **scaling**
alone are not considered synthetic features.

## T

## target

Synonym for **label**.

## temporal data

Data recorded at different points in time. For example, winter coat sales recorded for each day of the year would be temporal data.

## Tensor

The primary data structure in TensorFlow programs. Tensors are N-dimensional (where N could be very large) data structures, most commonly scalars, vectors, or matrices. The elements of a Tensor can hold integer, floating-point, or string values.

## Tensor Processing Unit (TPU)

An ASIC (application-specific integrated circuit) that optimizes the performance of TensorFlow programs.

## Tensor rank

See **rank**.

## Tensor shape

The number of elements a **Tensor** contains in various dimensions.
For example, a [5, 10] Tensor has a shape of 5 in one dimension and 10
in another.

## Tensor size

The total number of scalars a **Tensor** contains. For example, a
[5, 10] Tensor has a size of 50.

## TensorBoard

The dashboard that displays the summaries saved during the execution of one or more TensorFlow programs.

## TensorFlow

A large-scale, distributed, machine learning platform. The term also refers to the base API layer in the TensorFlow stack, which supports general computation on dataflow graphs.

Although TensorFlow is primarily used for machine learning, you may also use TensorFlow for non-ML tasks that require numerical computation using dataflow graphs.

## TensorFlow Playground

A program that visualizes how different
**hyperparameters** influence model
(primarily neural network) training.
Go to http://playground.tensorflow.org
to experiment with TensorFlow Playground.

## TensorFlow Serving

A platform to deploy trained models in production.

## test set

The subset of the data set that you use to test your **model**
after the model has gone through initial vetting by the validation set.

Contrast with **training set** and
**validation set**.

## tf.Example

A standard protocol buffer for describing input data for machine learning model training or inference.

## time series analysis

A subfield of machine learning and statistics that analyzes
**temporal data**. Many types of machine learning
problems require time series analysis, including classification, clustering,
forecasting, and anomaly detection. For example, you could use
time series analysis to forecast the future sales of winter coats by month
based on historical sales data.

## training

The process of determining the ideal **parameters** comprising
a model.

## training set

The subset of the data set used to train a model.

Contrast with **validation set** and
**test set**.

## transfer learning

Transferring information from one machine learning task to another.
For example, in multi-task learning, a single model solves multiple tasks,
such as a **deep model** that has different output nodes for
different tasks. Transfer learning might involve transferring knowledge
from the solution of a simpler task to a more complex one, or involve
transferring knowledge from a task where there is more data to one where
there is less data.

Most machine learning systems solve a *single* task. Transfer learning is a
baby step towards artificial intelligence in which a single program can solve
*multiple* tasks.

## true negative (TN)

An example in which the model *correctly* predicted the
**negative class**. For example, the model inferred that
a particular email message was not spam, and that email message really was
not spam.

## true positive (TP)

An example in which the model *correctly* predicted the
**positive class**. For example, the model inferred that
a particular email message was spam, and that email message really was spam.

## true positive rate (TP rate)

Synonym for **recall**. That is:

True positive rate is the y-axis in an **ROC curve**.

## U

## unlabeled example

An example that contains **features** but no **label**.
Unlabeled examples are the input to **inference**. In
**semi-supervised** and
**unsupervised** learning,
unlabeled examples are used during training.

## unsupervised machine learning

Training a **model** to find patterns in a data set, typically an
unlabeled data set.

The most common use of unsupervised machine learning is to cluster data into groups of similar examples. For example, an unsupervised machine learning algorithm can cluster songs together based on various properties of the music. The resulting clusters can become an input to other machine learning algorithms (for example, to a music recommendation service). Clustering can be helpful in domains where true labels are hard to obtain. For example, in domains such as anti-abuse and fraud, clusters can help humans better understand the data.

Another example of unsupervised machine learning is
**principal component analysis
(PCA)**.
For example, applying PCA on a
data set containing the contents of millions of shopping carts might reveal
that shopping carts containing lemons frequently also contain antacids.

Compare with **supervised machine learning**.

## V

## validation set

A subset of the data set—disjunct from the training set—that you
use to adjust **hyperparameters**.

Contrast with **training set**
and **test set**.

## W

## weight

A coefficient for a **feature** in a linear model, or an edge
in a deep network. The goal of training a linear model is to determine
the ideal weight for each feature. If a weight is 0, then its corresponding
feature does not contribute to the model.

## wide model

A linear model that typically has many
**sparse input features**. We refer to it as "wide" since
such a model is a special type of **neural network** with a
large number of inputs that connect directly to the output node. Wide models
are often easier to debug and inspect than deep models. Although wide models
cannot express nonlinearities through **hidden layers**,
they can use transformations such as
**feature crossing** and
**bucketization** to model nonlinearities in different ways.

Contrast with **deep model**.
